| Transfer Method |
Default is Upload; no other options available. |
| Application |
Specify network applications to control; multiple applications can be entered separated by ";". |
| HTTP(S) Protocol |
When checked, upload via HTTP and HTTPS is controlled. |
| Size Limit (>=Byte) |
Set the maximum data size allowed for upload. Default is 102,400 Bytes; uploads exceeding this size are restricted. |
| Website / Network Address |
Specify target websites or network addresses. Uploads to these sites will be controlled. Default is all websites. Supports manual input (www.example.com), wildcards, ";" or "," separators, or selecting from a category library. |
| FTP Protocol |
When checked, FTP uploads are controlled. |
| FTP Size Limit (>=Byte) |
Maximum FTP upload size. Default is 102,400 Bytes; uploads exceeding this size are restricted. |
| File Name |
Specify file names to control. Supports wildcards and ";" or "," separators. |
| Network Address Range |
Restricts FTP uploads to specific IP ranges. Default is all addresses. Supports manual input, wildcards, ";" or "," separators, or selecting from a category library. |
| Other Protocols |
When checked, TCP protocol uploads are controlled. |
| Other Protocols Size Limit (>=Byte) |
Maximum upload size for TCP uploads. Default is 102,400 Bytes; uploads exceeding this size are restricted. |
| Port Range |
Same meaning as in the Traffic Control Policy. |
| Website or Network Address |
Specify target websites or network addresses. Default is * to control all sites and addresses. Supports manual input of IP, IP ranges, wildcards, ";" or "," separators, or selecting from a category library. Example: 192.168.3.1;192.168.1.1-192.168.2.255;www.company.net;*baidu*. |
